HCM Antenna Radiation Pattern Calculation

Calculate and optimize Antenna Radiation Patterns with HCM Pattern Optimizer

Optimize horizontal and vertical Antenna Patterns

The signatory states have agreed on the procedure for the combination of horizontal and vertical antenna patterns, within the framework of the HCM agreement.

HCM patterns or envelopes are a generalized picture of the existing irregular radiation pattern of a radio antenna. HCM Pattern Optimizer is a tool for calculating antenna envelopes based on the HCM Agreement. Antenna patterns of the manufacturers are converted into the optimal HCM pattern.  The software can calculate multiple horizontal and vertical HCM patterns for an antenna pattern.

By combining HCM patterns, the levels of the same radio cell calculations lead to different field strengths (theoretical), which can lead to a situational optimization.

Features

  • 360° antenna radiation pattern improvement
  • Improvement of current type of antenna radiation pattern
  • Concurrent modification of several antennas in tabs
  • Optional meta data can be saved together with antenna
  • Turning offset angles of antennas
  • Quick and easy screenshot feature available
  • Multilingual (currently German and English implemented)

Views

Editions

Feature Comparison

Feature Free Version Full Version
Time limited No No
360° pattern optimization ✔︎ ✔︎
Optimization of current pattern types ✔︎ ✔︎
Parallel editing of multiple antennas in tabs ✔︎ ✔︎
Edit and save antenna meta information ✔︎ ✔︎
Turning antenna angle offset ✔︎ ✔︎
Easy screenshot capturing ✔︎ ✔︎
Open XML ✔︎ ✔︎
Save XML - ✔︎
New XML ✔︎ ✔︎
XML new entry ✔︎ ✔︎
Delete XML ✔︎ ✔︎
Rename XML ✔︎ ✔︎
Chart view linear / logarithmic ✔︎ ✔︎
Pattern calculation appendix 6 HCM V6 / 7 Only EA patterns ✔︎
Pattern display Thick lines ✔︎
Manufacturers import Only Kathrein ✔︎
Reporting Only JPG ✔︎
Angle optimization ✔︎ ✔︎
Manual data entry ✔︎ ✔︎
Parameter input ✔︎ ✔︎
Color selection ✔︎ ✔︎
Certification - ✔︎
All pattern types - ✔︎
Coordinate display - ✔︎
Maximizing windows - ✔︎
  Request download Get in touch

System Requirements

Hardware/Software Minimum Requirements
Processor performance 2.0 GHz
Memory (RAM) 1 GByte
Hard disk space 200 MByte
Operating system Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10
Display resolution 1024x768 pixel or more

Download

Quickstart guide

HCM pattern optimizer quickstart guide english

Download PDF — 718 KB
